PostPosted: Mon Nov 06, 2023 10:14 pm
Offline

Joined: Sun Oct 01, 2023 8:31 pm
Posts: 5
Asymmetrical clipping with two germanium diodes in series. Middle position is no clipping. Symmetrical clipping are silicon 1N1448. Three usuable tones. No other mods from the standard recipe. So happy.Image
Thank you for the follow up service after a build error on my part.

Eric.


Sent from my iPhone using Tapatalk


Top
 Profile

PostPosted: Tue Nov 07, 2023 9:52 am
Offline
Moderator
User avatar

Joined: Tue Jan 02, 2007 1:24 pm
Posts: 16252
Location: Albany, NY
Looks great! You should definitely be able to throw some poop with that one! :wink: :mrgreen:

_________________
“My favorite programming language is SOLDER” - Bob Pease (RIP)

My Website * My Musical Gear * My DIY Pedals: Pg.1 - Pg.2


Top
 Profile

PostPosted: Tue Nov 07, 2023 12:39 pm
Offline
Site Admin
User avatar

Joined: Sun Jan 22, 2006 1:39 pm
Posts: 6009
Location: Richland, WA
duhvoodooman wrote:
Looks great! You should definitely be able to throw some poop with that one! :wink: :mrgreen:


lol!

_________________
*patience is a virtue*

Please do not PM me. email is prefered. keith@buildyourownclone.com


Top
 Profile

PostPosted: Tue Nov 07, 2023 6:47 pm
Offline

Joined: Sun Oct 01, 2023 8:31 pm
Posts: 5
More pics for more amusement. I was expecting not to have room
for internal battery but it barely fit. The diode choice mod I got from Hello Sailor Effects/Joe Halliday on YouTube. https://youtu.be/Cc9Nee5O2qg?si=WyAS2V1IJt83VJ2I


Attachments:
IMG_0802.jpeg [ 367.12 KiB | Viewed 3819 times ]
IMG_0800.jpeg [ 302.41 KiB | Viewed 3819 times ]
IMG_0801.jpeg [ 659.05 KiB | Viewed 3819 times ]
Top
 Profile

PostPosted: Tue Nov 07, 2023 9:08 pm
Offline

Joined: Sun May 03, 2020 6:07 pm
Posts: 125
Location: Melbourne, Australia
Very nice :)

I think you missed a trick on the side, though -- you could have had a picture from the rear to indicate "ASSymetric" :lol:


Top
 Profile

PostPosted: Wed Nov 08, 2023 12:13 pm
Offline
Moderator
User avatar

Joined: Tue Jan 02, 2007 1:24 pm
Posts: 16252
Location: Albany, NY
eponymous wrote:
I think you missed a trick on the side, though -- you could have had a picture from the rear to indicate "ASSymetric" :lol:

Sorry to be "that guy," but the word is actually asymmetric. :roll: :mrgreen:

_________________
“My favorite programming language is SOLDER” - Bob Pease (RIP)

My Website * My Musical Gear * My DIY Pedals: Pg.1 - Pg.2


Top
 Profile

PostPosted: Wed Nov 08, 2023 4:50 pm
Offline

Joined: Sun May 03, 2020 6:07 pm
Posts: 125
Location: Melbourne, Australia
duhvoodooman wrote:
eponymous wrote:
I think you missed a trick on the side, though -- you could have had a picture from the rear to indicate "ASSymetric" :lol:

Sorry to be "that guy," but the word is actually asymmetric. :roll: :mrgreen:


Can't argue with that, but I was consistent with the label :wink:


Top
 Profile

PostPosted: Wed Nov 08, 2023 8:11 pm
Offline

Joined: Sun Oct 01, 2023 8:31 pm
Posts: 5
Mea culpa. I did mispell the word and sprayed clear coat over it....but a bigger regret is not having a South Park Five Assed Monkey graphic to put next to it.


Top
 Profile

PostPosted: Thu Nov 09, 2023 11:19 am
Offline
Site Admin
User avatar

Joined: Sun Jan 22, 2006 1:39 pm
Posts: 6009
Location: Richland, WA
You could probably work this one in somehow as well.


_________________
*patience is a virtue*

Please do not PM me. email is prefered. keith@buildyourownclone.com


Top
 Profile

PostPosted: Thu Nov 09, 2023 12:08 pm
Offline
Moderator
User avatar

Joined: Tue Jan 02, 2007 1:24 pm
Posts: 16252
Location: Albany, NY
Eric S wrote:
...but a bigger regret is not having a South Park Five Assed Monkey graphic to put next to it.

I think you've ascribed one extra ass to the South Park monkey, but here ya go for your next pedal project:

Attachment:
FAM.gif [ 25.63 KiB | Viewed 3722 times ]

_________________
“My favorite programming language is SOLDER” - Bob Pease (RIP)

My Website * My Musical Gear * My DIY Pedals: Pg.1 - Pg.2


Top
 Profile

PostPosted: Mon Nov 13, 2023 11:30 am
Offline
Moderator
User avatar

Joined: Sat Mar 11, 2006 12:49 am
Posts: 9000
Location: New Yawk, NY
:D :mrgreen: :lol:

_________________
Everyone likes sausage. Nobody wants to see how it's made.
